Underslung tank 68L for all variations of the Volkswagen Transporter range T5 from year 2003 to T6 current model including all 4Motion models. 12 cm flush tank lid as cleaning opening and 1x ½ inch brass threaded socket as inlet, 1x ½ inch as outlet and 1x ½ inch as vent. Installation and secure fastening under the vehicle with our Fitting Kit, consisting of: 2x stainless steel brackets & suitable screws for fastening. This underslung tank can be used as freshwater tank or wastewater tank and is installed in the empty spare wheel recess of the VW Transporter.
| Measurements (L*W*H) | 67*65*25 cm |
|---|
| Weight | 8.00 kg |
|---|
| Capacity | 68 L |
|---|
| Size BSP Outlet | 1/2" |
|---|
| Lid Size | 12 cm |
|---|
| Default Colour | Traffic Black (Ral 9017) |
|---|
| Length | 67.0 cm |
|---|
| Width | 65.0 cm |
|---|
| Height excl. Lid | 25.0 cm |
|---|
| Weight | 8.00 kg |
|---|
| Capacity | 68 L |
|---|
| Wall thickness | 6 mm |
|---|
| Material | MDPE |
|---|
| Size BSP Outlet | 1/2" |
|---|
| Lid Size | 12 cm |
|---|
| Default Colour | Traffic Black (Ral 9017) |
|---|
| Tank Type | Flat Tank |
|---|
| BSP Outlet | Yes |
|---|
| Spin Weld Outlet possible | No |
|---|
| Lid vented | No |
|---|
| Baffels | No |
|---|
Flat, round 68 litre underfloor tank for the spare wheel recess on the VW Transporter T5 & T6 with 12 cm tank cap, ½ inch inlet, ½ inch outlet & ½ inch vent
Our flat, round, black underslung tanks for the VW Transporter series are suitable for storing and transporting portable water or waste water. The underslung tanks each have a 1/2" threaded socket (internal thread made of brass) for the inlet, outlet and ventilation, which are always delivered open /drilled. The tank lid has a diameter of 12 cm without ventilation. The wall thickness of these underslung tanks for WV transporters is approx. 6 mm. For fastening / assembly under the vehicle / VW Transporter, we deliver a suitable assembly set with two stainless steel brackets and corresponding screws. After the underslung tank has been installed in the spare wheel recess, the spare wheel holder can be reinstalled in lowest setting for additional security.
